Bosch
0 986 015 320 Starter
SKU / part number
Bosch 0 986 015 320 Starter. Part no. 0-986-015-320. Check specifications, vehicle fitment and references below.
Specifications
Length
270 | mm
Voltage
12 V
Rated Power
1.7 kW
Number of mounting bores
2
Number of threaded holes
1
Number of Teeth
9
Clamp
50
Clamp
30
Flange Diameter
82.5 mm
Rotation Direction
Clockwise rotation
Pinion Rest Position
15 mm
Starter Type
Self-supporting
Thread Size 1
M8x1.25
Bore Diameter
9.5 mm
Bore Ø 3
9.5 mm
Position/Degree
rechts
Mounting Angle
120 degrees
Mounting bore angle measurement
120 degree
Trade Numbers
1532
Shipping details
Weight
4.717 Kg
Customs Code
851140
Country of Origin
Germany
Cross-Reference Numbers
| BOSCH | 0 001 110 007, 0 001 110 008, 0 986 015 323, 0 986 015 328 |
|---|---|
| DELCO REMY | DRS5320 |
| HC-PARTS | CS606 |
| HELLA | 8EA 730 176-001 |
| LINDE | 0009710107, 0009710197 |
| LUCAS ELECTRICAL | LRS00419, LRS02184, LRS2184, LRS419 |
| VW | 068 911 023 L, 068 911 023 LX |
