Graf
PA1097 Water pump
SKU / part number
Graf PA1097 Water pump. Part no. PA1097. Check specifications, vehicle fitment and references below.
Specifications
Operating Mode
Mechanical
Supplementary Article/Supplementary Info
with seal
Supplementary Article/Supplementary Info
with Radial Bearing
Supplementary Article/Supplementary Info
do not use sealant
Number of blades/vanes
10
Water Pump Pulley Diameter
52 mm
Impeller Diameter
70 mm
Water Pump Type
for toothed belt drive
Water pump impeller material
Metal
Shipping details
Weight
0.687 Kg
Customs Code
841330
Country of Origin
Italy
Cross-Reference Numbers
| AIRTEX | 1909, WPA-1909 |
|---|---|
| AUTOKIT | PA1515 |
| BGA | CP3386, CP3818 |
| BOSCH | 1 987, 949 766 |
| BUGATTI | PA10204 |
| CAR | 332760 |
| COMLINE | EWP441 |
| CONTINENTAL CTAM | WP6024 |
| DAYCO | DP901 |
| DOLZ | R234 |
| FIRST LINE | FWP2271 |
| FRECCIA | WP0300 |
| GATES | WP0065 |
| GGT | PA12606 |
| GK | 986957S |
| GNS | YH-N165-2, YH-RE141-4, YH-RE141-6 |
| GUTTMANN | 20220 586, 10 |
| HELLA | 8MP376800501 |
| HEPU | P957S |
| HUTCHINSON | WP96 |
| IDROMEC | PA37072 |
| INTERBRAKE | RN072 |
| JAPANPARTS | PQ-177 |
| JAPKO | 35177 |
| KWP | 101097 |
| MAGNETI MARELLI | 350984006000 |
| METELLI | 24-1097 |
| MEYLE | 16132200024 |
| NAPA | NWP1455 |
| NISSAN | 21010-00Q0N |
| OPEN PARTS | WAP8409.00, WAP8595.00 |
| OPTIMAL | AQ-2289 |
| PIERBURG | 701840020 |
| RENAULT | 77 01, 479 114 |
| RHIAG | WP1515 |
| RUVILLE | 65564 |
| SALERI | PA1515 |
| SASIC | 3604017 |
| STARLINE | 20174540S |
| SUZUKI | 17410-67JG1 |
| SWAG | 60929703 |
| Schaeffler INA | 538039310 |
| TEMOT | 85-8468 |
| VAICO | A38-50006 |
| VALEO | 526001 |
