Mahle
009 86 01 Piston
SKU / part number
Mahle 009 86 01 Piston. Part no. 009-86-01. Check specifications, vehicle fitment and references below.
Specifications
Length
84.0 | mm
Cylinder Bore
88.6 mm
Compression Height
57.0 mm
Bolt Length
67.0 mm
Bolt Head Diameter
31.0 mm
Recess Depth 1
18.1 mm
Recess Diameter
38.0 mm
Machined
with cut-out for oil jet
Surface
Coated
Supplementary Article/Supplementary Info 2
with piston ring carrier
Supplementary Article/Supplementary Info 2
with cooling duct
Top Land Height
8 mm
Connecting Rod Design
Trapezoidal Connecting Rod
Production Number
88 L 110
Component Number
1. T 2.5 CrK
Component Number
2. M 2.0
Component Number
3. DSF 2.5 Cr
Net Weight
1047 g
Packaging length
11.6 cm
Packaging width
11.60 cm
Packaging height
14.30 cm
Shipping details
Weight
0.946 Kg
Customs Code
840999
Country of Origin
Germany
Cross-Reference Numbers
| IVECO | 0000002995563, 2995563 |
|---|---|
| KOLBENSCHMIDT | 40 28562 0 |
| NÜRAL | 87-138008-00 |
